65''/75''/86'' High Brightness LCD panel

Description

  • The high brightness lcd panel with open frame design is with original LG industrial panel and our back-light design .
  • It's super slim bezel and with bracket installation ,which can be compatible for different enclosure or device used .

  • Different sizes from 21.5inch to 86inch available .


Features

  • High brightness 2000nits -3000nits
  • Light sensor to adjust the brightness automaticly
  • Open frame design with bracket ,more compatible .
  • Aluminum case can be better for heat spread.
  • Original LG/BOE industrial panel


Reference Dimension

  • 65″:1469*844*55mm(H*W*D)

  • 75″:1683*975*55mm(H*W*D)

  • 86″:1928*1120*55mm(H*W*D)



Detail specifications

Panel
Panel BrandLG /BOE
Panel size65″/75″/86″
Resolution2160*3840
Aspect Ratio16:09
Brightness(nits)2500nits - 3000nits
Contrast Ratio1400:1
Gray to Gray Response Time(ms)8
Viewing Angel178°/178°
Backlight configurationWLED
Operating Life (hours)50000-60000h
Media Player for option
Operating SystemConfigurationStorage
Driver boardHDMI, VGA, DVINone
StandaloneAndroid A20(HDMI, USB)8G
AndroidAndroid RK3288(HDMI, USB)2G+16G
Windows

Intel I3/I5/I7(HDMI, VGA, USB)

4G+120G SSD
Power
Input VoltageAC100-240V, 50/60HZ
Enviroment
Operating EnviromentOutdoor
Operating Temperature0°C~+55°C
Storage Temperature-10°C~+60°C
Humidity10%-80% RH Non-condensing
